IGS Audio Vanad 500 (B-Ware)
699,00 €*
Verfügbarkeit: Bitte kontaktieren Sie uns in dringenden Fällen.
Produktinformationen "IGS Audio Vanad 500 (B-Ware)"
IN – input level: from 0dB(Line) to +30dB(Mic); step = 3dB
OUT – output level: from +0dB to +30dB; step = 3dB
HPF switch – 6dB/Oct high pass filter: OFF/30/100Hz
Ø switch – phase reverse: ON/OFF
+48V switch – phantom power: ON/OFF
XLR/HiZ – input: HiZ(front)/XLR(rear)
Technical specification
- API 500 standard module
- Preamp Mic/Line/HiZ
- Input impendance:1kΩ – Carnhill transformer balanced
- Output impendance:600kΩ – Carnhill transformer balanced
- Max input level(LINE): +20 dBu
- Max output level: +22 dBm
- Amplification: 60 dB
- PAD from -30 to 0 dB, step 3dB
- Phantom power +48V
- HPF filter: OFF, 30, 100 Hz
- Phase reverse
- Harmonic distortion THD: up to 0,2%
- Frequency response: +/- 0.1 dB 20Hz do 20kHz
- Signal-noise: over 99 dB
- Power supply: +/- 16V
- Current consumption: 60mA
- Dimensions: (h*w*d) 132x37x158mm
- Mass: 900g.
