Lake People DIGI-TOOL F622

Lake People DIGI-TOOL F622

Produktinformationen "Lake People DIGI-TOOL F622"

2 x 1 in 8 WCLK/AES-id SPLITTER F622

- 2 modules with each 1 input and 8 outputs
- Inputs and outputs unbalanced, impedance 75 ohms via BNC sockets
- High sensitive inputs to regenerate unproper or weak input signals
- High output voltages to drive long distances
- Jumpers to switch the output impedance from 75 ohms to 50 ohms to drive improper WCLK inputs
- Jumpers to switch to AES-3id operation
- Jumpers to switch to “Superclock 256 Fs”

The MULTI-SYNC OPTION offers the following features:

  • - 3 external inputs AES/EBU, AES-id, WCLK
  • - 1 AES-EBU sync output
  • - Internal oscillators with 32, 44.1, 48, 88.2, 96, 176.4, 192 kHz
  • - Failsafe operation through switchable Auto-Mode
  • - Multimode power supply 90 … 260V AC
  • - 19”, 1 U stainless steel case, front dark grey




Technische Daten

  •      Inputs:    2 x BNC unbalanced
  •      Input impedance:    75 ohms
  •      Input sensitivity:    < 200 mV
  •
  •      Outputs:    2 x 8 BNC unbalanced
  •      Output impedance:
  • 75 ohms / 50 ohms
  •      Output level:    > 2,3 Vss / 3,4 Vss
  •      Output jitter:    < 1 nS
  •
  •      Special Function:    - Output impedance switchable to 50 ohms
  •           - Outputs switchable to AES-3id operation
  •           (1 Vss / 75 ohms)
  •
  • - Outputs switchable to “Superclock
  •           256 Fs” operation
  •
  •      Power supply:    90 … 260 V AC, 12 VA
  •      Dimensions:    483x44x166 mm (WxHxD), 19", 1U
  •      Case:    Stainless steel
  •      Finish:    Front dark grey
  •      OPTION:    SYNC UNIT
