Drawmer MC1.1 Monitor PreAmp
659,00 €*
Verfügbarkeit: Bitte kontaktieren Sie uns in dringenden Fällen.
Produktinformationen "Drawmer MC1.1 Monitor PreAmp"
MC1.1 - Monitor PreAmp
The Drawmer MC1.1 is a Monitor Pre-Amplifier width the same fantastic transparent and non-colouring sound like the well known MC2.1. MC1.1 has a a revised feature set more suitable for a less complex post production booth or home use where multiple speaker setups are not permissible or even required, and with the addition of a new RIAA phono stage the MC1.1 is a great solution for a precious turntable setup.
The front panel is dominated by the two large, independent volume controls for the main line outs and the headphone amplifier, both incorporate a paralleled custom quad pot for excellent channel matching and the smoothest possible action. There are also individual switches for each input source and output section making an elegantly simple yet functional user interface. In addition to balanced XLR inputs of MC1.1 includes an input for MP3 player, iPod or smartphone and a line / phone input for turntables or CD players.
Feature
- Ultra low noise and transparent circuit design.
- Linear power supply with low hum toroidal transformer and internal voltage selector switch.
- 3 Input Sources
- Balanced XLR, MP3 Player 3.5mm Jack & Switchable Line/Phono (RIAA MM) RCA.
- Two switchable output stages, Balanced XLR and RCA.
- Mono Sub woofer output available simultaneous to balanced outs.
- Parallelled custom quad pots on main and headphone level controls for excellent channel matching and smooth feel.
- Independent volume controls for the main outputs and headphone section.
- Rugged steel chasis and stylish brushed aluminium cover.
- Can be stacked and is rack mountable (with the MCB 2U mounting kit).
- Dimensions: L 272mm x W 215mm x H 81mm.
- Weight: 2.5kg.
- Designed and manufactured by Drawmer in the UK
- Optional 2U rack mounting kit available
| Sicherheits- und Warnhinweise: | Die spezifischen Sicherheitshinweise für das Produkt sind in dessen Bedienungsanleitung aufgeführt. |
|---|
Drawmer Electronics Ltd
Drawmer Electronics Ltd
Coleman Street, Parkgate, Rotherham, South Yorkshire,S62 6EL
mail@drawmer.com
https://www.drawmer.com/
Technical Specifications
- Input Level (max): 21dBu
- Output Level (max): 21dBu
- Dynamic range: 118dB @ unity gain
- Crosstalk: L/R @ 1kHz >85dB
- THD+N: 0,0014%
- Frequency response: 20Hz-20kHz +/- 0.2dB
- Phase response: 20Hz-20kHz +/- 2degrees max
- Power requierements: 115V or 230V at 50-60Hz, 20VA switch
- Dimensions (D x W x H): 272 x 215 x 81 mm
- Weight: 2.5kg
