Equi=Tech MODEL Q 1.5RQ

Equi=Tech MODEL Q 1.5RQ

Produktinformationen "Equi=Tech MODEL Q 1.5RQ"

Features:

  • Bifilar Wound Isolation Transformer — This patented method of winding AC power transformers is the most accurate way known to achieve a near perfect balanced output.  The bifilar wound secondary is an exclusive Equi=Tech feature that raises the performance level of each of our products above all the rest.  To achieve peak performance in electronic components, a perfectly balanced AC supply is crucial.  Bifilar winding the output of our transformers achieves this near perfect mirror image symmetry.  Because every product offered by Equi=Tech is bifilar wound, every product provides a more effective and broader range of noise attenuation compared to any other balanced power product (typically >6dB gain better.)  This holds true in high resolution electronic components of all different shapes and sizes.  The result is improved signal, greater definition in video and greater detail in audio program material.  IT and other EDP systems also benefit from significantly fewer timing errors and higher throughput.
  • High Power Factor — Regardless of how clean AC power provided for sensitive electronics may be, the instant that component power switches are turned on, the quality of AC power degenerates.  This is simply the nature of what are termed “non-linear reactive loads.”  When non-linear power supplies are energized, some measure of power is wasted and reflected back out onto the line.  This undesirable and noisy form of energy (harmonics) is then shared by every other component on the system.  Furthermore, voltage and current phases are knocked out of sync too and this is what is referred to as low power factor.  Electricity by its nature requires both current and voltage to be present at the same time or nothing happens.  In AC power, current and voltage must be timed together in sync or to the degree they are not, nothing happens.  As the power factor drops lower and lower, electricity thins out very much like cheaper gasoline and equipment performance suffers.  Generally speaking, the greater the load (e.g. large amplifiers) the lower the resulting power factor.  However, when this reflected energy flows back up the line into a balanced transformer, reactive currents will be flowing in opposite directions through identical mirror image output coils thereby creating equal but opposite electromagnetic forces that are present in the transformer in the same instant.  This causes the nuisance reflected energy (harmonics) to cancel out and literally disappear without bleeding back out onto the originating power grid.  Furthermore reactive load currents null (cancel out) electrically at the ground because harmonics on each side of the line are equal but opposite in polarity to each other – but not just opposite, precisely opposite thanks to bifilar winding.  This causes cancellation of all of the undesirable non-linear load harmonics on the load side of the transformer too.  What’s left?  Pure 60Hz AC once again with nothing remaining on the line to skew power factor; even the ground remains clean.  AC power remains as coherent and clean as it was originally provided before component switches were turned on.  Bifilar winding is the only way this undesirable non-linear event can be accurately addressed and its effects eliminated in real time as it happens.  The impact that this improved power stability and cleaner ground have on the performance of sensitive electronics is astonishing.
  • Ultra Low Impedance — The ultra-low impedance design of the Model Q transformer provides unrestricted current delivery to its output and virtually busts the “myth” that transformers cannot handle high amplitude current transients demanded by amplifiers and other types of high current pulse loads.  Unlike typical transformers that are often considered to be “too current restricting” (and rightfully so,) Model Q transformers have been engineered with radical modifications made to their core and winding specifications which result in a transformer that has uncommonly low impedance and unrestricted current handling characteristics.  They provide instantaneous current response with the capacity to handle much larger current transients than any comparable solid state AC generator or inverter system. The amplitude of the current transients a Model Q transformer can easily accommodate would likely explode any similar solid state based device and it does this effortlessly with almost no measureable current sag.  In technical jargon, the magnetic flux density of its core operates at a fraction of its capacity thereby providing an extreme amount of current headroom with a magnetic current transfer hysteresis curve that is far more linear than anything similar to it, even when driven at or near its maximum continuous power rating.  It is virtually impossible detect any significant current sag or to drive a Model Q transformer into saturation.  Furthermore, the line-to-ground impedance on its output is only a fraction of the line-to-ground impedance found in similarly rated solid state systems.  This means that Model Q transformers attenuate a much wider bandwidth of non-linear reactive load harmonics (noise) than any comparable “low impedance” solid state AC generator or inverter.
  • 100% Passive Circuitry — There are no active components used in any Equi=Tech product.  There is nothing that will degrade from heat over time or from years of rugged use.  Similar systems may use semiconductor devices to drive their outputs or soft start relays to compensate for a low quality isolation transformer with high inrush current — not ours!  There is nothing in an Equi=Tech system to wear out over time from heavy use or from heat.  We invest the cost of building our systems where it belongs, in well designed high quality components.  The next time you are watching a live broadcast of the Super Bowl or a Presidential Inauguration, remember that Equi=Tech is running the show because engineers know when equipment failure is not an option.  Ruggedness, reliability and the most refined balanced power technology on Earth is why top professionals choose Equi=Tech.
  • High Efficiency — Equi=Tech systems are the most efficient of their kind.  This means that very little power is inefficiently wasted when powering electronic components.  Even when driven hard, they generate very little heat and they are barely warm to the touch.  They draw very little power in idle mode and can be left turned on indefinitely, ready to meet extreme power demands in an instant.  In operational mode, they waste almost no power drawing approximately what they put out.  With a typical 97%+ efficiency rating, they elegantly outperform similar power products and do it in a safe, economical and environmentally friendly way.
  • Magnetic and Faraday Shielding — These indispensable features are included in every Equi=Tech product.  The Faraday shields isolate noise from the outside world as well as protect the system’s output and connected load components from potentially destructive voltage spikes. The magnetic shield assures that electronics used in close proximity will be unaffected by magnetic stray field radiation.
  • Oxygen-free copper wire— Mil Spec. oxygen-free copper wire is used throughout the entire AC distribution section of every Model “Q”.  Hand-made OFC jumper wires and wiring harnesses are used exclusively in their assembly.  OFC wire reduces high frequency micro current distortion that is commonly present in conventional copper or silver wired circuits.  This further extends the effective bandwidth of noise attenuation.
  • Filtered Digital Equipment Outlets — These outlets provide additional high frequency noise attenuation and isolation for switching power supplies typically found in digital electronics.  The outlets are intended for use with CD Players, DVD Players, Dish Receivers, Hi-Definition TV’s, DLP and Plasma Displays, automation controllers, computers and other high resolution electronic digital system components.
  • Unswitched Outlet — An entire system of components can be turned on and off from the front panel by using the front standby switch(es).  As a convenience, one outlet on the back panel remains constantly turned on for equipment that uses a date/time clock such as TIVO’s, VCR’s, PVR’s, DVR’s and other components that require constant power to maintain volatile memory.
  • Quality Tested — Equi=Tech products have been tested and certified to meet the most rigorous and demanding of all power industry standards for Class A (high voltage) power distribution equipment.  No one other than Equi=Tech offers a balanced power system that meets the design criteria and safety testing procedures required in this standard.  Since Equi=Tech started the balanced power revolution in the early 90’s, we remain the only balanced power manufacturer committed to meeting high performance and safety standards required by discriminating professionals in many technical fields.  Equi=Tech makes the only systems that meet stringent OSHA standards governing safety in the workplace.  Unlike some manufacturers, we cut no corners in the design and fabrication of our systems.  We regard electrical safety as seriously as we regard performance and we are willing to go the extra mile to prove it.  We are professionals who value our integrity and demonstrate it by the way we design and build our products.
  • Lifetime Warranty — Only Equi=Tech offers a lifetime warranty on the most expensive component and heart of the system, the power isolation transformer.  We are so confident that our systems will last a lifetime, we offer this transformer replacement warranty for as long as the original chassis remains in tact; and it’s the only transferable warranty of its kind.  If for any reason (other than abuse) the transformer fails, we will replace it at our expense and charge only for nominal shipping and handling cost
Sicherheits- und Warnhinweise: Die spezifischen Sicherheitshinweise für das Produkt sind in dessen Bedienungsanleitung aufgeführt.

EQUI=TECH

Equi=Tech, LLC

1630 Williams Hwy. #433 Grants Pass, Oregon 97527
