Merging Technologies

All Anubis units delivered by us are Dante Ready, meaning they can be equipped with the appropriate Dante channel licenses. We’re happy to provide more information on this. Alternatively, we also offer Non-Dante Anubis units at discounted prices. MERGING+ANUBIS Seamless Protection Switching, has been developed specifically to address the demands of broadcast facilities depending on an IP infrastructure. Incorporating client requests to go beyond the ST2110 capability of Anubis, SPS includes no compromise ST2022-7 class C and NMOS compliance. It provides the most efficient and cost-effective solution to AoIP stream monitoring and management. ST2022-7 Seamless Protection SwitchingAdding to the fantastic and constantly evolving feature set of Anubis, the Anubis SPS version features two network ports for ST2022-7 compliance. NMOSWhile all MERGING Devices can be discovered and inter connected using MERGING ANEMAN Network Manager, ANUBIS SPS (as well as all other Merging interfaces) is also capable to register itself into an NMOS server as well as comply to connection requests from a compliant NMOS Network Manager such as VideoIPath from Nevion.ANUBIS+SPS is compliant with: NMOS IS-04 (Discovery & Registration)  NMOS IS-05 (Device Connection Management) SMPTE ST2110MERGING holds strongly to its commitment to broadcasters and has been implementing all the new IP protocols into its products. As a regular participant in IP Showcase events, Merging has implemented ST2110 and AES67. Anubis SPS meets the demanding requirements of JT-NM and is self-certified. We want your trust to be based on objective quality and reliability and submitting all our products to independent testing bodies is vital to ensure interoperability. RAVENNA / AES67 Built-InUsing RAVENNA (AES67 compatible), Anubis is able to provide flexible connectivity of every single input and output across standard networks, using off-the-shelf network equipment. The future is most definitely networked audio, and Anubis provides it today. Read more about RAVENNA DC or POE powered... Or BOTH!Protect your production with not only audio network seamless switching but also power switching! Connect Anubis to both DC and POE supply. Should one fail, Anubis will switch to the other seamlessly. Accessible And Controllable RemotelyWith remote productions becoming the standard and content creators spread around the world, it is paramount to be able to quickly remote into any production device configuration and operation panels without wasting time on the phone running the user through the device. Anubis configuration, presets and features are completely accessible remotely for very fast troubleshooting and deployment. Switch Mode!There is another good news about Anubis SPS which is that it can be used in switch mode instead of “redundant ST2022-7 mode”, removing the necessity to have a network switch in scenarios where a DAW simply needs to be connected to a Horus, Hapi or Anubis, i.e. when doing a mobile recording. ANUBIS SPS – SYSTEMS INTEGRATIONAnubis SPS together with the Merging Audio Device, opens remarkable possibilities. MAD is a multi-ASIO driver (also with WDM support) that has an infrastructure option that supports ST2022-7, ST2110, NMOS and Virtual Machine control. This recognizes that centralized data centers and server-based installations are now the new normal way to manage the global nature of the broadcast industry.

Without Dante Ready expansion. MERGING+ANUBIS Seamless Protection Switching, has been developed specifically to address the demands of broadcast facilities depending on an IP infrastructure. Incorporating client requests to go beyond the ST2110 capability of Anubis, SPS includes no compromise ST2022-7 class C and NMOS compliance. It provides the most efficient and cost-effective solution to AoIP stream monitoring and management. ST2022-7 Seamless Protection SwitchingAdding to the fantastic and constantly evolving feature set of Anubis, the Anubis SPS version features two network ports for ST2022-7 compliance. NMOSWhile all MERGING Devices can be discovered and inter connected using MERGING ANEMAN Network Manager, ANUBIS SPS (as well as all other Merging interfaces) is also capable to register itself into an NMOS server as well as comply to connection requests from a compliant NMOS Network Manager such as VideoIPath from Nevion.ANUBIS+SPS is compliant with: NMOS IS-04 (Discovery & Registration)  NMOS IS-05 (Device Connection Management) SMPTE ST2110MERGING holds strongly to its commitment to broadcasters and has been implementing all the new IP protocols into its products. As a regular participant in IP Showcase events, Merging has implemented ST2110 and AES67. Anubis SPS meets the demanding requirements of JT-NM and is self-certified. We want your trust to be based on objective quality and reliability and submitting all our products to independent testing bodies is vital to ensure interoperability. RAVENNA / AES67 Built-InUsing RAVENNA (AES67 compatible), Anubis is able to provide flexible connectivity of every single input and output across standard networks, using off-the-shelf network equipment. The future is most definitely networked audio, and Anubis provides it today. Read more about RAVENNA DC or POE powered... Or BOTH!Protect your production with not only audio network seamless switching but also power switching! Connect Anubis to both DC and POE supply. Should one fail, Anubis will switch to the other seamlessly. Accessible And Controllable RemotelyWith remote productions becoming the standard and content creators spread around the world, it is paramount to be able to quickly remote into any production device configuration and operation panels without wasting time on the phone running the user through the device. Anubis configuration, presets and features are completely accessible remotely for very fast troubleshooting and deployment. Switch Mode!There is another good news about Anubis SPS which is that it can be used in switch mode instead of “redundant ST2022-7 mode”, removing the necessity to have a network switch in scenarios where a DAW simply needs to be connected to a Horus, Hapi or Anubis, i.e. when doing a mobile recording. ANUBIS SPS – SYSTEMS INTEGRATIONAnubis SPS together with the Merging Audio Device, opens remarkable possibilities. MAD is a multi-ASIO driver (also with WDM support) that has an infrastructure option that supports ST2022-7, ST2110, NMOS and Virtual Machine control. This recognizes that centralized data centers and server-based installations are now the new normal way to manage the global nature of the broadcast industry.

All Anubis units delivered by us are Dante Ready, meaning they can be equipped with the appropriate Dante channel licenses. We’re happy to provide more information on this. Alternatively, we also offer Non-Dante Anubis units at discounted prices. MERGING+ANUBIS Seamless Protection Switching, has been developed specifically to address the demands of broadcast facilities depending on an IP infrastructure. Incorporating client requests to go beyond the ST2110 capability of Anubis, SPS includes no compromise ST2022-7 class C and NMOS compliance. It provides the most efficient and cost-effective solution to AoIP stream monitoring and management. ST2022-7 Seamless Protection SwitchingAdding to the fantastic and constantly evolving feature set of Anubis, the Anubis SPS version features two network ports for ST2022-7 compliance. NMOSWhile all MERGING Devices can be discovered and inter connected using MERGING ANEMAN Network Manager, ANUBIS SPS (as well as all other Merging interfaces) is also capable to register itself into an NMOS server as well as comply to connection requests from a compliant NMOS Network Manager such as VideoIPath from Nevion.ANUBIS+SPS is compliant with: NMOS IS-04 (Discovery & Registration)  NMOS IS-05 (Device Connection Management) SMPTE ST2110MERGING holds strongly to its commitment to broadcasters and has been implementing all the new IP protocols into its products. As a regular participant in IP Showcase events, Merging has implemented ST2110 and AES67. Anubis SPS meets the demanding requirements of JT-NM and is self-certified. We want your trust to be based on objective quality and reliability and submitting all our products to independent testing bodies is vital to ensure interoperability. RAVENNA / AES67 Built-InUsing RAVENNA (AES67 compatible), Anubis is able to provide flexible connectivity of every single input and output across standard networks, using off-the-shelf network equipment. The future is most definitely networked audio, and Anubis provides it today. Read more about RAVENNA DC or POE powered... Or BOTH!Protect your production with not only audio network seamless switching but also power switching! Connect Anubis to both DC and POE supply. Should one fail, Anubis will switch to the other seamlessly. Accessible And Controllable RemotelyWith remote productions becoming the standard and content creators spread around the world, it is paramount to be able to quickly remote into any production device configuration and operation panels without wasting time on the phone running the user through the device. Anubis configuration, presets and features are completely accessible remotely for very fast troubleshooting and deployment. Switch Mode!There is another good news about Anubis SPS which is that it can be used in switch mode instead of “redundant ST2022-7 mode”, removing the necessity to have a network switch in scenarios where a DAW simply needs to be connected to a Horus, Hapi or Anubis, i.e. when doing a mobile recording. ANUBIS SPS – SYSTEMS INTEGRATIONAnubis SPS together with the Merging Audio Device, opens remarkable possibilities. MAD is a multi-ASIO driver (also with WDM support) that has an infrastructure option that supports ST2022-7, ST2110, NMOS and Virtual Machine control. This recognizes that centralized data centers and server-based installations are now the new normal way to manage the global nature of the broadcast industry.

Without Dante Ready expansion. MERGING+ANUBIS Seamless Protection Switching, has been developed specifically to address the demands of broadcast facilities depending on an IP infrastructure. Incorporating client requests to go beyond the ST2110 capability of Anubis, SPS includes no compromise ST2022-7 class C and NMOS compliance. It provides the most efficient and cost-effective solution to AoIP stream monitoring and management. ST2022-7 Seamless Protection SwitchingAdding to the fantastic and constantly evolving feature set of Anubis, the Anubis SPS version features two network ports for ST2022-7 compliance. NMOSWhile all MERGING Devices can be discovered and inter connected using MERGING ANEMAN Network Manager, ANUBIS SPS (as well as all other Merging interfaces) is also capable to register itself into an NMOS server as well as comply to connection requests from a compliant NMOS Network Manager such as VideoIPath from Nevion.ANUBIS+SPS is compliant with: NMOS IS-04 (Discovery & Registration)  NMOS IS-05 (Device Connection Management) SMPTE ST2110MERGING holds strongly to its commitment to broadcasters and has been implementing all the new IP protocols into its products. As a regular participant in IP Showcase events, Merging has implemented ST2110 and AES67. Anubis SPS meets the demanding requirements of JT-NM and is self-certified. We want your trust to be based on objective quality and reliability and submitting all our products to independent testing bodies is vital to ensure interoperability. RAVENNA / AES67 Built-InUsing RAVENNA (AES67 compatible), Anubis is able to provide flexible connectivity of every single input and output across standard networks, using off-the-shelf network equipment. The future is most definitely networked audio, and Anubis provides it today. Read more about RAVENNA DC or POE powered... Or BOTH!Protect your production with not only audio network seamless switching but also power switching! Connect Anubis to both DC and POE supply. Should one fail, Anubis will switch to the other seamlessly. Accessible And Controllable RemotelyWith remote productions becoming the standard and content creators spread around the world, it is paramount to be able to quickly remote into any production device configuration and operation panels without wasting time on the phone running the user through the device. Anubis configuration, presets and features are completely accessible remotely for very fast troubleshooting and deployment. Switch Mode!There is another good news about Anubis SPS which is that it can be used in switch mode instead of “redundant ST2022-7 mode”, removing the necessity to have a network switch in scenarios where a DAW simply needs to be connected to a Horus, Hapi or Anubis, i.e. when doing a mobile recording. ANUBIS SPS – SYSTEMS INTEGRATIONAnubis SPS together with the Merging Audio Device, opens remarkable possibilities. MAD is a multi-ASIO driver (also with WDM support) that has an infrastructure option that supports ST2022-7, ST2110, NMOS and Virtual Machine control. This recognizes that centralized data centers and server-based installations are now the new normal way to manage the global nature of the broadcast industry.

8 Channel Mic/Line A/D and D/A Card for Hapi Mk III – Premium VersionThe ADA8V3P is a complex input and output card for the Merging audio mainframe Hapi Mk III. With eight inputs and eight outputs, it offers two-way audio conversion: analog to digital and digital to analog. These remote controlled Mic/Line Input and Output cards feature 3rd generation Dual Gain topology, inspired by the exceptional Anubis preamps, for highest audio quality without compromise. With two ADA8V3P 8-channel Mic/Line In and Line Out Cards you can configure Hapi Mk III for up to 16 analog I/O channels. The Premium card ADA8V3P has superior specifications and supports sample rates up to 352.8 kHz (DXD) and 384 kHz as well as bitstream formats up to DSD256.

8 Channel Mic/Line A/D and D/A Card for Hapi Mk IIIThe ADA8V3S is a complex input and output card for the Merging audio mainframe Hapi Mk III. With eight inputs and eight outputs, it offers two-way audio conversion: analog to digital and digital to analog. These remote controlled Mic/Line Input and Output cards feature 3rd generation Dual Gain topology, inspired by the exceptional Anubis preamps, for highest audio quality without compromise. With two ADA8V3S 8-channel Mic/Line In and Line Out Cards you can configure Hapi Mk III for up to 16 analog I/O channels. The ADA8V3S supports sample rates of up to 192 kHz.

8 Channel Mic/Direct Outs A/D Card for Hapi Mk III – Premium VersionThe ADO8V3P input card is an outstanding addition to the Merging Hapi Mk III audio mainframe. With 8 mic/line inputs, it delivers unparalleled audio quality and a dynamic range of an impressive 139 dB (A). The Swiss-designed preamps offer up to 78 dB of gain with exceptional transparency, thanks to Merging’s unique 3rd generation dual gain topology design. Its remote accessibility allows you to easily adjust all parameters for each channel. The ADO8V3P sets a new standard in audio circuit design, and it even includes analog direct outs (post-mic-pre) for monitoring or external processing. The Premium card ADO8V3P has superior specifications and supports sample rates up to 352.8 kHz (DXD) and 384 kHz as well as bitstream formats up to DSD256.

8 Channel Mic/Direct Outs A/D Card for Hapi Mk IIIThe ADO8V3S input card is an outstanding addition to the Merging Hapi Mk III audio mainframe. With 8 mic/line inputs, it delivers unparalleled audio quality and a dynamic range of an impressive 139 dB (A). The Swiss-designed preamps offer up to 78 dB of gain with exceptional transparency, thanks to Merging’s unique 3rd generation dual gain topology design. Its remote accessibility allows you to easily adjust all parameters for each channel. The ADO8V3S sets a new standard in audio circuit design, and it even includes analog direct outs (post-mic-pre) for monitoring or external processing. The ADO8V3S supports sample rates up to 192 kHz.

Mic Pre-Amp + ADC Mic Pre Max Input (Mic+Pad / Mic / Boost) +24 dBu / +12 dBu / +0 dBu Mic Pre Max Input (Pad On; Pad Off) > 3 kΩ; 10.4 kΩ Input Impedance (Zlo; ZHi) > 3 kΩ; 10.4 kΩ Dynamic Range (flat 20 Hz-20 kHz) > 134 dB Dynamic Range (A-weighted, typ) 136 dB Gain Range (software controlled) 0 dB to +66 dB Gain Precision ±0.2 dB Gain Step 0.5 dB THD+N Pre + A/D (20 Hz-20 kHz) @ -2 dBFS -110 dB (0.00031 %)/-112 dB (0.00025 %) Interchannel Crosstalk @ 1kHz, typ. <-125dB Interchannel Crosstalk @ 20Hz – 20 kHz < -100 dB EIN @ >40 dB Gain (150Ω Source Impedance, A-weighted, typ) -128 dBu Common Mode Rejection Rate @ 1kHz, typ. 75 dB (up to -20 dBFS) Common Mode Rejection Rate @ 20Hz – 20 kHz > 60 / 65 dB (up to -20 dBFS) Phantom Power (Software Switchable Per Channel) +48 Volts Phase Reverse Switch (Software Switchable Per Channel) Yes Low Cut filter (Software Switchable Per Channel) -12 dB/octave, 80 Hz Line Input Frequency response +0/-0.1dB @ fs = 44100 Hz 5.7 Hz - 20.5 kHz Frequency response +0/-1.0dB @ fs = 44100 Hz 1.8 Hz - 21.0 kHz Frequency response +0/-0.1dB @ fs = 96000 Hz 5.7 Hz - 43.9 kHz Frequency response +0/-1.0dB @ fs = 96000 Hz 1.8 Hz - 45.4 kHz Frequency response +0/-0.1dB @ fs = 192000 Hz 5.7 Hz - 42.1 kHz Frequency response +0/-1.0dB @ fs = 192000 Hz 1.8 Hz - 64.7 kHz Frequency response +0/-0.1dB @ fs = 384000 Hz 5.7 Hz – 40 kHz Frequency response +0/-1.0dB @ fs = 384000 Hz 1.8 Hz - 75 kHz Max Line Input for 0 dBFS +24 dBu Input Impedance 10.4 kΩ Dynamic Range (flat 20 Hz-20 kHz), ref +24 dBu > 136 dB Dynamic Range (A-weighted, typ), ref +24 dBu 138.5 dB THD+N Line+A/D (1 kHz) @ -2 dBFS, Typ. -106 dB (0.0005%)/-109 dB (0.00035%) THD+N Line+A/D (20 Hz-20 kHz) @ -2 dBFS < -106 dB Interchannel Crosstalk @ 1kHz, typ. -130 dB Interchannel Crosstalk @ 20Hz – 20 kHz < -100 dB Sensitivity Range for 0 dBFS (software controlled) -42 dBu to +24 dBu Gain Precision ±0.2 dB Gain Step 0.5 dB Common Mode Rejection Rate @ 1kHz, typ. 75 dB (up to -20 dBFS) Common Mode Rejection Rate @ 20Hz – 20 kHz > 65 dB (up to -20 dBFS) Group Delay (1FS) 5/fs Group Delay (2FS) 5/fs Group Delay (4FS) / Premium (8FS) 6/fs / 7/fs

Mic Pre-Amp + ADC Mic Pre Max Input (Mic+Pad / Mic / Boost) +24 dBu / +12 dBu / +0 dBu Mic Pre Max Input (Pad On; Pad Off) > 3 kΩ; 10.4 kΩ Input Impedance (Zlo; ZHi) > 3 kΩ; 10.4 kΩ Dynamic Range (flat 20 Hz-20 kHz) > 134 dB Dynamic Range (A-weighted, typ) 136 dB Gain Range (software controlled) 0 dB to +66 dB Gain Precision ±0.2 dB Gain Step 0.5 dB THD+N Pre + A/D (20 Hz-20 kHz) @ -2 dBFS -110 dB (0.00031 %)/-112 dB (0.00025 %) Interchannel Crosstalk @ 1kHz, typ. <-125dB Interchannel Crosstalk @ 20Hz – 20 kHz < -100 dB EIN @ >40 dB Gain (150Ω Source Impedance, A-weighted, typ) -128 dBu Common Mode Rejection Rate @ 1kHz, typ. 75 dB (up to -20 dBFS) Common Mode Rejection Rate @ 20Hz – 20 kHz > 60 / 65 dB (up to -20 dBFS) Phantom Power (Software Switchable Per Channel) +48 Volts Phase Reverse Switch (Software Switchable Per Channel) Yes Low Cut filter (Software Switchable Per Channel) -12 dB/octave, 80 Hz Line Input Frequency response +0/-0.1dB @ fs = 44100 Hz 5.7 Hz - 20.5 kHz Frequency response +0/-1.0dB @ fs = 44100 Hz 1.8 Hz - 21.0 kHz Frequency response +0/-0.1dB @ fs = 96000 Hz 5.7 Hz - 43.9 kHz Frequency response +0/-1.0dB @ fs = 96000 Hz 1.8 Hz - 45.4 kHz Frequency response +0/-0.1dB @ fs = 192000 Hz 5.7 Hz - 42.1 kHz Frequency response +0/-1.0dB @ fs = 192000 Hz 1.8 Hz - 64.7 kHz Frequency response +0/-0.1dB @ fs = 384000 Hz 5.7 Hz – 40 kHz Frequency response +0/-1.0dB @ fs = 384000 Hz 1.8 Hz - 75 kHz Max Line Input for 0 dBFS +24 dBu Input Impedance 10.4 kΩ Dynamic Range (flat 20 Hz-20 kHz), ref +24 dBu > 136 dB Dynamic Range (A-weighted, typ), ref +24 dBu 138.5 dB THD+N Line+A/D (1 kHz) @ -2 dBFS, Typ. -106 dB (0.0005%)/-109 dB (0.00035%) THD+N Line+A/D (20 Hz-20 kHz) @ -2 dBFS < -106 dB Interchannel Crosstalk @ 1kHz, typ. -130 dB Interchannel Crosstalk @ 20Hz – 20 kHz < -100 dB Sensitivity Range for 0 dBFS (software controlled) -42 dBu to +24 dBu Gain Precision ±0.2 dB Gain Step 0.5 dB Common Mode Rejection Rate @ 1kHz, typ. 75 dB (up to -20 dBFS) Common Mode Rejection Rate @ 20Hz – 20 kHz > 65 dB (up to -20 dBFS) Group Delay (1FS) 5/fs Group Delay (2FS) 5/fs Group Delay (4FS) / Premium (8FS) 6/fs / 7/fs

DeNoiserPyramix’s DeNoiser and DeScratcher options have been specially developed for Merging by Algorithmix to make best use of the processing power available in the system resulting in a very powerful, high quality and real-time restoration package. The DeNoiser Plug-In is a single-ended noise reduction system. This means it will operate to remove broadband noise artifacts directly from an existing signal and does not need any special encoding procedure before recording.

DeNoiserPyramix’s DeNoiser and DeScratcher options have been specially developed for Merging by Algorithmix to make best use of the processing power available in the system resulting in a very powerful, high quality and real-time restoration package. The DeNoiser Plug-In is a single-ended noise reduction system. This means it will operate to remove broadband noise artifacts directly from an existing signal and does not need any special encoding procedure before recording.Cedar Audio Restoration Suite for PyramixA full range of restoration processes for Merging Technologies' "Pyramix" systems. Remove clicks, crackle, thumps, and hiss using the best restoration tools within the Pyramix environment, and ensure that your audio is free of all unwanted sounds and noises using the latest revision of CEDAR Retouch™. DeScratcherThe De-Scratcher PlugIn effectively removes clicks and crackles from old vinyl and shellac (78rpm) records, or audio recordings tainted by switching noise, digital cross-talk, or thyristor buzz. Unlike other systems, Pyramix’s De-Scratcher is real-time and works virtually without artifacts, providing the correct setting for all parameters.

DeScratcherThe De-Scratcher PlugIn effectively removes clicks and crackles from old vinyl and shellac (78rpm) records, or audio recordings tainted by switching noise, digital cross-talk, or thyristor buzz. Unlike other systems, Pyramix’s De-Scratcher is real-time and works virtually without artifacts, providing the correct setting for all parameters.

Algorithmix ReNOVAtor for Pyramix: We recommend users to download the latest version available on their site. Cedar: Install issue on certain Vista configurations where you might not see the Cedar plug-ins after the installation process. The problem is due to erroneous referencing of the license manager utility on a vista machine. Please contact Merging Support or Cedar Support for all details and workaround. Cedar: Some toolbar icons might be missing if on a Windows XP system. Workaround: Disable the Skin option in Pyramix>settings>Desktop Layout. Altiverb: We recommend users to download the latest version available on the Audio Ease site. UAD2: Certified as working with Pyramix, see forum known issues Eucon not detected under Win7 x64 Workaround: Make sure that you install both the x64 and then the x86 Eucon drivers.

All Anubis units delivered by us are Dante Ready, meaning they can be equipped with the appropriate Dante channel licenses. We’re happy to provide more information on this. Alternatively, we also offer Non-Dante Anubis units at discounted prices.MERGING+ANUBIS Seamless Protection Switching, has been developed specifically to address the demands of broadcast facilities depending on an IP infrastructure. Incorporating client requests to go beyond the ST2110 capability of Anubis, SPS includes no compromise ST2022-7 class C and NMOS compliance. It provides the most efficient and cost-effective solution to AoIP stream monitoring and management. ST2022-7 Seamless Protection SwitchingAdding to the fantastic and constantly evolving feature set of Anubis, the Anubis SPS version features two network ports for ST2022-7 compliance. NMOSWhile all MERGING Devices can be discovered and inter connected using MERGING ANEMAN Network Manager, ANUBIS SPS (as well as all other Merging interfaces) is also capable to register itself into an NMOS server as well as comply to connection requests from a compliant NMOS Network Manager such as VideoIPath from Nevion.ANUBIS+SPS is compliant with: NMOS IS-04 (Discovery & Registration)  NMOS IS-05 (Device Connection Management) SMPTE ST2110MERGING holds strongly to its commitment to broadcasters and has been implementing all the new IP protocols into its products. As a regular participant in IP Showcase events, Merging has implemented ST2110 and AES67. Anubis SPS meets the demanding requirements of JT-NM and is self-certified. We want your trust to be based on objective quality and reliability and submitting all our products to independent testing bodies is vital to ensure interoperability. RAVENNA / AES67 Built-InUsing RAVENNA (AES67 compatible), Anubis is able to provide flexible connectivity of every single input and output across standard networks, using off-the-shelf network equipment. The future is most definitely networked audio, and Anubis provides it today. Read more about RAVENNA DC or POE powered... Or BOTH!Protect your production with not only audio network seamless switching but also power switching! Connect Anubis to both DC and POE supply. Should one fail, Anubis will switch to the other seamlessly. Accessible And Controllable RemotelyWith remote productions becoming the standard and content creators spread around the world, it is paramount to be able to quickly remote into any production device configuration and operation panels without wasting time on the phone running the user through the device. Anubis configuration, presets and features are completely accessible remotely for very fast troubleshooting and deployment. Switch Mode!There is another good news about Anubis SPS which is that it can be used in switch mode instead of “redundant ST2022-7 mode”, removing the necessity to have a network switch in scenarios where a DAW simply needs to be connected to a Horus, Hapi or Anubis, i.e. when doing a mobile recording. ANUBIS SPS – SYSTEMS INTEGRATIONAnubis SPS together with the Merging Audio Device, opens remarkable possibilities. MAD is a multi-ASIO driver (also with WDM support) that has an infrastructure option that supports ST2022-7, ST2110, NMOS and Virtual Machine control. This recognizes that centralized data centers and server-based installations are now the new normal way to manage the global nature of the broadcast industry.

Mergings Komplettlösung für das Dolby Atmos-Mixing ist im Vergleich zu herkömmlichen Systemen kompakt, benutzerfreundlich und anpassungsfähig. Dank der Zusammenarbeit mit Sonarworks umfasst das Bundle eine automatische Kalibrierungsfunktion für das Dolby Atmos Monitoring. Das mitgelieferte Mikrofon und die SoundID Reference-Software erlauben es dem Benutzer, den Raum schnell und präzise zu kalibrieren und die gewünschte Zielfrequenzkurve anzupassen. Erfahrene Tontechniker haben darüber hinaus die Möglichkeit zur manuellen Kalibrierung mit integrierten Verzögerungen, Trims und EQ-Bändern.  Der mitgelieferte Anubis bietet eine umfassende Monitoring-Engine mit 128 Eingangskanälen, unterstützt verschiedene Formate und Lautsprecherkonfigurationen und enthält Lautsprechersteuerungen, Downmixing und Routing zu Cue-Mixes. Er dient als zentrales Element für Monitoring / Control-Room Cue und I/O, ist kompakt und kann mit allen DAWs genutzt werden. Außerdem kann er ASIO, WDM, Core Audio oder AVID digilink unterstützen.  Anubis verfügt außerdem über absolute HighEnd Kopfhörerausgänge, Mikrofon-Vorverstärker und AD-Wandler. Die Integration eines Dolby Atmos Renderers oder weiterer DAWs wird durch den MAD / VAD AES67-Treiber ohne zusätzliche Audio Interfaces oder Wandler für MAC, Windows und Linux ALSA möglich. Hapi MkIII, auch Teil des Bundles, bietet Flexibilität bei den I/Os. Mit PT64-Karten können mehrere Hapi MkII bis zu 128 Digilink-Kanäle für ein HDX2- oder HDX3-System unterstützen.  RAUMKALIBRIERUNG FÜR ANUBIS SoundID Reference MICROPHONE  SoundID Reference for Multichannel SOFTWARE  SoundID Reference ANUBIS PLUGIN  MONITORING ENGINE MERGING+ANUBIS PRO SPS  DA FÜR LAUTSPRECHERAUSGÄNGE (UND MEHR) MERGING+HAPI MKIII  inkl 2x DA8 cards for 16 line outputs  inkl 2x breakout cables DOLBY APPROVED AES67 TREIBER FÜR RENDERER/DAW MERGING Virtual Audio Device (VAD)

Merging Techologies AVC INTRA Support

Merging Technologies Cable, Analog In DB-25 - Octal XLR Female, 1.5 meter

Merging Technologies Cable, Analog Out DB-25 - Octal XLR Male, 1.5 meter

Merging Technologies Cable, Digital DB-25 - Quad XLR Female/Male, 1.5 meter

The Merging Technologies COMMENTARY MISSION FOR ANUBIS is a dedicated software option that expands the functionality of the Anubis networked audio interface for commentary and broadcast applications. It provides specialized tools for commentator workflows, monitoring, communication, and audio routing, making it suitable for live broadcasting, sports production, event coverage, and studio environments. Designed to integrate seamlessly with the Anubis ecosystem, the Commentary Mission delivers a streamlined user experience tailored to professional commentary operations.

Pyramix MASSCORE D-USR (Double Upgrade & Support Renewal)The Pyramix MASSCORE D-USR package is intended for customers whose MASSCORE engine is two major releases behind the current version. It provides a direct upgrade path to the latest MASSCORE engine while restoring eligibility for technical support throughout the next software lifecycle.Upgrade to the Latest MASSCORE EngineWith the D-USR package, users can move from an older MASSCORE generation directly to the latest engine release and benefit from the newest performance enhancements, processing improvements, and platform updates. This renewal applies exclusively to the MASSCORE engine and does not include upgrades for Pyramix or Ovation software packs. A corresponding D-USR for the associated software package must be purchased separately.Renewed Support and License ManagementD-USR reactivates access to technical support services, ensuring assistance remains available while using the current MASSCORE version. The package also includes complimentary license key transfers and ownership name changes, providing greater flexibility when administering licenses across multiple systems and users.Upgrade RequirementsThis D-USR package is designed for customers whose MASSCORE engine is two major versions behind the latest release. To complete the upgrade, a MASSCORE D-USR must be purchased together with the appropriate Pyramix or Ovation Pack D-USR.For example, customers upgrading from Pyramix PREMIUM 14 with MASSCORE to Pyramix PREMIUM 16 with MASSCORE must purchase both a Pyramix PREMIUM D-USR and a MASSCORE D-USR.Users whose MASSCORE engine is only one major version behind the current release do not require a D-USR. In such cases, a standard MASSCORE USR can be purchased alongside the corresponding Pyramix or Ovation Pack USR. For example, upgrading from Pyramix PREMIUM 15 with MASSCORE to Pyramix PREMIUM 16 with MASSCORE requires a MASSCORE USR together with a Pyramix PREMIUM USR.

Ovation ELEMENTS – Double Upgrade and Support Extension Included in the D-USR package: Upgrade access: Allows you to upgrade from the second-to-last version to the latest Pyramix version. Includes all minor updates and bug fixes up to the next major version.Retention of existing options: All existing options remain active. New features assigned to your package are provided at no additional cost as soon as your license key is reissued or activated after purchase.Technical Support: Free access to support services such as license transfers and name changes, valid until the next major version. Update Notifications: Stay informed via our Knowledge Base or the MT Portal as soon as updates, hotfixes, or new features are released.MassCore Users: A valid MassCore USR+ is required to maintain access to the MassCore engine. Compatibility and Eligibility: Eligibility: This offer is valid for Ovation ELEMENTS owners who are two major versions behind the latest version. For users who are one major version behind, please refer to the USR offer (Upgrade and Support Extension).

Ovation PREMIUM D-USR (Double Upgrade & Support Renewal)Ovation PREMIUM is the most advanced show-control and media playback platform from Merging Technologies, designed for professional entertainment productions, immersive attractions, and broadcast environments. Initially developed for large-scale theme park installations, it is equally suited to cruise ships, theatres, and complex live event venues. The software integrates seamlessly with Dataton WATCHOUT and Ross Video systems while providing powerful real-time recording, editing, playback, and immersive audio capabilities through Flux SPAT and Dolby Atmos workflows.D-USR Package BenefitsThe Double Upgrade & Support Renewal (D-USR) package enables users running software that is two major releases behind to move directly to the latest Ovation PREMIUM version while renewing technical support coverage.Upgrade to the Current ReleaseGain access to the newest Ovation software version, including all current features, improvements, maintenance releases, and fixes delivered within the current product generation.Preservation of Existing OptionsAll licensed features and options remain active after the upgrade. Additional functionality included within your software package becomes available upon license activation or reissuance.Renewed Technical SupportD-USR restores eligibility for Merging Technologies support services, including complimentary key transfers and license ownership updates through the next major release cycle.Software Update NotificationsUsers continue to receive information regarding updates, hotfixes, and newly available features through the MT Portal and official knowledge base.MassCore RequirementCustomers using the MassCore engine should also maintain a valid MassCore D-USR or USR+ plan to retain access to MassCore updates and support.EligibilityThis D-USR package is intended for customers operating Ovation PREMIUM installations that are two major versions behind the current release. Systems that are only one version behind should use the standard USR package.Advanced FeaturesDolby Atmos ADM PlaybackImport Dolby Atmos ADM files directly as cues for immediate playback through either a Dolby Atmos Renderer or the integrated Merging Renderer. Combined with the MassCore Engine, installations with up to 384 dedicated loudspeakers can be supported.Flux SPAT and Dolby Atmos ConnectivityDesigners can freely combine object-based audio, multichannel bus formats, and Ambisonics workflows within a single project. Ovation integrates natively with Flux SPAT and Dolby Atmos rendering environments for advanced immersive productions.OSC CommunicationFull OSC send and receive functionality enables extensive customization and integration with external devices, software platforms, and automation systems.Automation RecordingAutomation data, including OSC commands, can be recorded and replayed, helping production teams recreate immersive audio experiences consistently throughout rehearsals and performances.Hybrid Immersive Audio WorkflowSupport for traditional channel-based audio and Ambisonics workflows is included. Higher-order Ambisonics decoding up to seventh order is available with the optional VR Pack, while first- and second-order decoding are always supported.Mixer EnhancementsThe mixing environment includes matrix-style bus routing, mouse-wheel navigation, movable VCA and Group strips, routing presets, and expanded predefined speaker configurations.ANEMAN 1.2 IntegrationANEMAN 1.2 provides support for MERGING+ANUBIS and ZOEM devices, unicast routing, enhanced network discovery and zone management, and Ross device plug-in compatibility.
